leak detection systems

For whole house monitoring

MANUAL CONTROL

SYSTEMS

AT201

FROM ONLY $199.95

REMOTE CONTROL

SYSTEMS

AT302

FROM ONLY $349.95

HARD WIRED

SYSTEMS

AT401

FROM ONLY $399.95

AT201   -  Manual Control System

The AT201 is a programmable Leak Detection System with automatic  shutoff valve. It is easily fitted inline on your main incoming water pipe, and acts as a Water Safety Trip Switch, monitoring all your plumbing. It is designed to detect the difference between your normal water use and a leak, and will shut off the water if a leak is detected or a tap, hose or appliance is left running.



Simple to use with only one button to control all functions. It is powered by a long life battery (supplied) so needs no wiring or electrical connection, and can be mounted above or below ground either inside or outside*.   It can be used in Houses, Apartments or Commercial washroom applications.



The AT201 also has a selectable Sleep Mode for use with Irrigation systems or if used to monitor public washrooms, it can sleep during very busy periods of non stop water use by patrons.



  • Patented Leak Sensor with integrated shutoff valve, shuts off water once leak is detected

  • Leak Detection Sensing System is programmable to operate in almost any application

  • Fast Test Facility allows rapid check of system functions

  • Powered by long life 9v battery (supplied)

  • Two digit LED status display

  • Leak counter display (up to 99) with counter reset facility

  • Simple stand alone installation - no wires to connect

  • Input port for connection to optional external reset switches or movement sensors

  • Sleep Mode for use with Irrigation or for peak hours in busy commercial facilities

  • Easy one button operation for all functions and programming

  • Low battery warning indicator - water turns off

  • Battery power level indicator on LED status display

  • Temporary System Override facility

  • Emergency manual Total System Override facility

  • Service Plug supplied allows for Control Unit maintenance

  • Early Warning Indication warns user before water is shut off

  • Submersible installation allowed (To 2m Depth - Equiv to IP68+)



System available with a choice of PVC or 316 Stainless Steel Shutoff Valves to suit your incoming pipe size and material.

* subject to environmental conditions - see Installation Manual

AT201 with 20mm

316 Stainless Steel Valve

option shown

AT201 - Manual Control Leak Detection System
AU$199.95Price


AT302 -  Deluxe Remote Control System

The AT302 is a fully programmable, autonomous Leak Detection System with an integrated automatic Shutoff Valve. It is designed to detect leaks and thus help to minimize water damage, reduce water bills and stop water wastage. It will constantly monitor all the plumbing pipes, fittings and water using appliances on the property, and like a trip switch, will shut off the water automatically if a tap, fitting, pipe, hose, toilet cistern or appliance is leaking or left running. It can detect the difference between your normal water use and a plumbing leak or tap left running by mistake, and alert you to plumbing problems as they occur, which you may other wise be unaware of.

The AT302 is very simple to install and use. A wireless Control Panel is used to control and program the system, which is powered by long life batteries and needs no wiring or electrical or WiFi connection. It monitors all water flow 24/7/365 and responds automatically to any leaks detected with no intervention required by the user. The wireless compact design allows for installation above or below ground, inside or outside the house or building.

It has advanced fully programmable protection features such as Home/Away mode, Nightwatch, Smart Auto Away sensing, System Self Monitoring protocols and Sleep Modes to minimise the response time to leaks. It can be programmed to also ignore irrigation systems which may use excessive water for long time periods.

Its low cost and simple installation and operation make it perfect for use in apartments or residential houses or commercial washrooms alike, where it can provide silent, invisible and automatic plumbing protection.


  • Patented Leak Sensor with integrated shutoff valve, shuts off water once leak is detected

  • Wireless portable Control Panel to easily program and control the system

  • Fast Test Facility allows rapid check of system functions.

  • System Check Function assists in quick identification of leaks when detected

  • Leak Detection Sensing System has Peak / Off Peak water usage modes to enhance detection capability

  • Early Warning Indicator warns user before water is shut off -  prevents water turning off unexpectedly.

  • Home/Away modes for increased leak detection protection - Automatic or Manual settings available

  • Nightwatch mode for increased overnight leak detection sensitivity

  • Sleep Mode  -  programmable leak detection Exclusion Period disables flow monitoring during the set time. Eg: when using garden irrigation systems, or during busy office hours in commercial washrooms

  • Trip Counter logs each time valve is tripped and keeps record of most recent trip event

  • Flow Indicator shows water flow on Control Panel

  • Temporary System Override from Control Panel for occasional longer than normal water usage.

  • Emergency Manual Override if system needs to be turned off for building work/maintenance

  • Battery power level indicator on Control Panel with low battery warning alarm

  • Water can be shut off from Control Panel, no need to access the incoming main tap.

  • System has inbuilt self monitoring protocol to check and maintain functionality

  • Replaceable mesh filter protects units from debris in water supply

  • Optional wireless Wetness Sensors available for more localised leak detection

  • Available with either PVC or S/Steel Shutoff Valves —  sizes from 15mm to 50mm available

AT302 - Remote Control Leak Detection System
AU$349.95Price



AT401 - Deluxe Hard Wired System

The AT401 is one of the most advanced Water Management, Leak Detection and Control Systems available on the market today. Designed to look as smart as it is functional, it uses a sleek wall mount Control Panel from which the user can control all the functions and programming of the system. The ultimate and most advanced water safety Trip Switch for plumbing protection.

The Control Panel is connected by a low voltage signal cable to the Shutoff Valve, which is mounted inline on your main incoming water pipe. This allows the AT401 to monitor all the plumbing in the house.

The AT401 is powered by a plug in 12v transformer and has a built in backup battery in case of mains power failure. It can be finely programmed for optimum leak protection, and can also be optionally connected to most water meters with a pulse output to provide a real time consumption display so you can monitor and be aware of exactly how much water you are using and its approximate cost. (Please check if your meter is compatible, feature not available in all markets).

  • Wall mount deluxe Control Panel with large backlit LCD display allows easy control of the system
  • Patented Leak sensor with integrated Shutoff Valve, shuts off water once leak is detected
  • Cable connection between the Control Panel and the Shutoff Valve for instant response (8 meter cable supplied with optional 6 meter extensions available as required)
  • Back up battery in case of mains power failure
  • Water Flow indicator on the Control Panel for instant visual confirmation of water flow or a potential leak
  • Fast Test Facility allows rapid check of system functions
  • Leak Detection system has Peak and Off peak water usage modes to enhance detection capability
  • Early Warning Indicator alerts user to impending water shut off - e.g. prevents user being caught in the shower with no water
  • Home/Away mode for increased leak detection protection - Automatic or Manual settings available
  • Nightwatch mode for increased overnight leak detection sensitivity
  • Sleep Mode - Programmable Exclusion Period disables Flow Sensor when required - e,g, for when using garden irrigation
  • Short term system override from Control Panel for occasional longer than normal water usage
  • Emergency manual override facility if system needs to be turned off for building work/maintenance
  • Water can be shut off from the Control Panel - no need to access the incoming main tap for plumbing maintenance
  • Replaceable mesh filter protects units from debris in water supply
  • Accessory Port may allow connection of movement sensors, extra reset switches or water meter inout signal.
  • System has variable outputs to trigger a BMS or Alarm System to give remote notification of a change of system status
  • Can display water consumption and cost if connected to existing water meter (may require additional optional cable and only if the  water  meter has a compatible pulse output).
  • System available with a choice of PVC or 316 Stainless Steel Shutoff Valves to suit your incoming pipe size or material
AT401 - Hard Wired Leak Detection System
AU$399.95Price

Purchase an

AquaTrip Online

AquaTrip

around the world

How can an

Aquatrip help

AVAILABLE IN AUSTRALIA FROM:

TERMS, CONDITIONS OF SALE & WARRANTY:

Click HERE.

ABOUT US

AquaTrip is a permanently installed Leak Detection System with an integrated automatic Shutoff Valve.

It functions as a Water Trip Switch, constantly monitoring all the plumbing pipes, fittings and water using appliances on the property.



If it detects a leak, a tap left running or some other plumbing failure, it will shut off the water automatically, to minimise water damage, prevent excess water bills and save water.



You can easily turn the water back on when required.
